Overall Dimension   (mm×mm×mm)

8000×2500×3490

Wheel base   (mm)

3200+1350

Curb weight （ kg ）

11800

Max Speed （ Km/h ）

≥80

Dimension for Upper body ：

4800*2300*1200mm=13m3

Bottom 6 mm ， side 4 mm ， Front Lifting

Engine

Model

WP10.290E32 ， water-cooled ， four strokes ， 6 cylinders straight in line ， turbocharged,

Fuel type

Diesel

Emission

EURO2 Mechanic Pump

Rated Power / rotating

213Kw(290hp)/2200rpm

Maximum Torque/ rotating speed

1160Nm/1200-1600rpm

Displacement

9726

Fuel tanker capacity （ L ）

300L aluminum

Clutch

Model

Φ 430, Diaphragm Spring ， Hydraulic boosting

Gearbox

Model

9JS135 ， mechanism, 9 forward gears,

1 reverse gear, manual operated,

Gear ratio of speed

12.65/8.38/6.22/4.57/3.40/2.46/1.83/1.34/1.00

R1: 13.22

Brake system

Service brake

Brake gap can be adjusted automatically, double circulation air brake system

Assistant brake

Engine exhaust brake

Park brake

Potential springs pressing on middle and rear wheels

Steering system

Model

D50 , whole circulation in ball type, hydraulic boosting

Suspension System

Front Suspension

Non-free standing leaf spring ， telescopic shock absorber with stabilizer bar suspension ， 9pcs spring

Rear Suspension

Non-free standing stabilization spring ， stabilization suspension ， 10pcs.

Frame

Same width, same sections: 280×80×8+5mm

(Benz Technology)

Front axle (Mercedes Benz Technology)

Double-shoe pneumatic brake, 5.5t no-driving steering axle

Middle and Rear axle (Mercedes Benz Technology)

Double-shoe pneumatic brake, ductile casting casing, with hub redactor, 13tons single reduction driving axle, speed ratio4.875

Tire

11.00R20

Qty of tire

11

Electrical system

Battery

2X12V/135Ah

Generator

28V-70A

Starter

5.4Kw/24V

Cab

NG80B Short cab without sleeper

Full steel skeleton structure, covered with double layer steel plate;

Can be tipped forwardly;

Interior trimming:

Integral interior trimming, Integral instrument, digital instrument, radio (with USB interface+MP3), high back/shock absorption seat for driver, high back seat for co-driver. Steering wheel can be adjusted. With inner A/C 。

Exterior trimming:

Metal bumper, three steps, new mirror ， outside sun visor
